Everycom EC 58C | 80mm USB Direct Thermal Printer
- 300mm/s Ultra High-Speed Printing, Improves Your Printing Efficiency
- Rich interface: Ethernet + USB , Cash Drawer Integration
- Auto Cutter ( Full / Half Cutting ) , Built in Web Server.
- Compatible with ESC / POS Print Instruction Mode
- Supports Windows, Linux, Android and iOS system printing
SKU: EC58C
Product Overview
Everycom EC-801 Printer is a high-quality thermal printer for network and kitchen printing. 300mm/s of high-speed printing. Excellent water-resistant, oil proof, dustproof structure design. Rich interface selection including Ethernet. Print status real-time monitoring and large input buffer, to avoid losing any bills, embedded IE server, configure printers more convenient. So many leading technologies beyond the performance of similar products, allowing you to enjoy high-quality, free from worry print experience.
Efficient features
This thermal printer has a printing mechanism which operates at a speed of 90mm/sec or 24 line/sec.
Low Noise Levels
These thermal printers generally have reduced noise levels which make them ideal for using in several work environments.
No Cartridge Required
The printer has no cartridge requirement as it prints with the help of heat, thereby reducing printing costs.
Compatibility
This Everycom Thermal Printer is compatible with windows 7, 8 and 10. Thus it is compatible with a range of operating systems and is very functional.
Easy to use
It is very easy to install a paper roll into this printer with the top open feature and it also has easy functional buttons that do not create unnecessary complexity.
| Model | EC-58 |
|---|---|
| Printing Method | Thermal Line Printing |
| Installation | Horizontally |
| Standard Accessories | Roll Paper x 1 (For checking the initial movement of the printer) CD-ROM (Drivers, Utility Software, Manuals) Paper Bering, USB Cable Power Cable |
| Weight | Approx. 0.6kg |
Technical Specifications
| Brand | Everycom |
|---|---|
| Font | 9x17 / 12x24, Hanji Font: 24x24, Thai Font: 9x24 / 12x24 |
| Character Size (W x H) | 0.88x2.13mm / 1.25x3mm, Hanji Font: 3x3mm, Thai Font: 0.88x3mm / 1.25x3mm |
| Character Set | 95 Alphanumeric, 18 set International, 128×43 pages (including user-defined page) Hanzi: Simplified Chinese : GB18030-2000:28,553 Barcode: UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN), CODE39, ITF, CODEBAR (NW-7), CODE93, CODE128, GS1-128, Gs1 DataBar Two-dimensional code: PDF417, QRCode, MaxiCode, 2D Gs1 DataBar Composite Symbology |
| Characters Per Inch | 22.6cpi / 16.9cpi, Hanji Font: 7.8cpi, Thai Font : 22.6cpi / 16.9cpi |
| Interface | USB, (Optional Interfaces : Serial Rs232, Bluetooth, WiFi, GPRS) |
| Buffer | 2048K bytes, NV Flash : 256K bytes |
| Print Speed | Max 120mm/s |
| Dot Density | 208x208 dpi |
| Paper (Roll Paper (Width & Roll Diameter) | 57.5 ± 0.5 (W) × dia. 83.0 |
| Power | DC +12V ± 5% |
| Operating | Approx. 3A (Mean/Print ratio 18% with print pattern) |
| Standby | Approx. 0.1A (Mean) |
| Cash Drawer Power Supply | DC 12V 1A |
| Overall Dimensions (D x W x H) | 185x115x130mm |
| Cash Drawer Integration | Yes Supported |
Manual
| Everycom EC 58C | Click here to Download Manual |
|---|
Drivers
| Everycom EC 58C | Click Here to Download Driver |
|---|
